MEP Modelling & Coordination

Conflict-Free MEP Systems Through Precision BIM

Eliminating on-site rework with high-accuracy Mechanical, Electrical, and Plumbing modelling.

The Core Offering

​In complex construction, the smallest intersection error between a duct and a beam can cost thousands in delays. At Scanotrek, we specialize in creating coordinated MEP models that ensure every pipe, tray, and duct fits perfectly within the structural envelope.

Our MEP Specializations

Mechanical (HVAC)

Detailed ductwork modelling, air handling units, and cooling system layouts optimized for airflow and space.

Electrical

Accurate routing of cable trays, conduits, lighting fixtures, and communication systems.

Plumbing

Precise modelling of domestic water, drainage, and specialized piping systems.

Fire Protection

Coordinated fire sprinkler systems and alarm layouts.

Clash Detection & Resolution

We don't just model; we coordinate. Using Autodesk Navisworks, we perform:

Hard Clash Detection:

Identifying physical intersections between systems.

Soft Clash Detection:

Ensuring proper clearance for maintenance and insulation.

Workflow Optimization:

Providing a detailed "Clash Report" to resolve issues in the digital phase—not the construction phase.

Deliverables

Coordinated 3D MEP Models (LOD 300 - 400).

Detailed Shop Drawings & Spool Drawings.

MEP Quantity Take-offs (BOQs).

Builders’ Work Openings (Sleeves and Wall penetrations).

High-Performance HVAC Engineering & BIM Integration

Delivering energy-efficient, coordinated, and standard-compliant Heating, Ventilation, and Air Conditioning solutions.

The Core Offering

Effective HVAC design is the lungs of a building. At Scanotrek, we go beyond simple drafting. We provide comprehensive HVAC solutions that optimize indoor air quality and thermal comfort while minimizing energy consumption. By integrating our 15 years of Revit expertise, we ensure that every duct and chiller is perfectly coordinated with the building’s architectural and structural constraints.

Our HVAC Engineering Services

  1. Heat Load Calculations & Sizing
  • ​Technical Detail: Performing detailed thermal analysis based on building orientation, occupancy, and climate data (using industry-standard tools like HAP or Elite).
  • ​The Benefit: We ensure equipment is perfectly sized—neither undersized (leading to discomfort) nor oversized (leading to wasted energy and costs).
  1. ​Ductwork Design & 3D Modeling
  • ​Technical Detail: Designing efficient air distribution systems, including supply, return, and exhaust ductwork in a 3D BIM environment.
  • ​The Benefit: Optimized static pressure and airflow, resulting in quieter systems and lower operational costs.
  1. ​Chilled Water & Piping Layouts
  • ​Technical Detail: Detailed routing of chilled water pipes, condenser water systems, and refrigerant piping.
  • ​The Benefit: Precision-modeled slopes and insulation clearances that prevent on-site installation conflicts.
  1. ​Equipment Selection & Layouts
  • ​Technical Detail: Strategically placing AHUs (Air Handling Units), FCUs, Chillers, and VRF systems to maximize space and accessibility for maintenance.
  • ​The Benefit: Clean, functional plant rooms that comply with international safety and maintenance standards.

Technical Standards & Compliance

Our designs are developed in accordance with global engineering benchmarks to ensure approval in the world and Indian markets:

ASHRAE

American Society of Heating, Refrigerating and Air-Conditioning Engineers.

SMACNA

Sheet Metal and Air Conditioning Contractors' National Association.

ISHRAE

Indian Society of Heating, Refrigerating and Air Conditioning Engineers.

Local Building Codes

Tailored to regional humidity and temperature requirements.

The Scanotrek HVAC Advantage

  1. BIM-Driven Coordination: We use Navisworks to perform clash detection between HVAC ducts and other services (Electrical, Plumbing, Structural), ensuring zero-error execution.
  2. ​Scan-to-HVAC: For renovation projects, we use laser scans to map existing tight ceiling voids, ensuring new ductwork fits the as-built reality perfectly.
  3. ​Sustainable Design: Focused on reducing the carbon footprint of buildings through smart ventilation and energy-efficient equipment selection.

Safe, Efficient, and Fully Coordinated Electrical Systems

Delivering comprehensive electrical engineering and 3D modeling for residential, commercial, and industrial infrastructure.

The Core Offering

​Electrical systems are the nervous system of any building. At Scanotrek, we provide end-to-end electrical design services that prioritize safety and energy efficiency. By utilizing Revit MEP, we move beyond 2D schematics to create intelligent 3D models that account for every conduit, cable tray, and panel board, ensuring a seamless integration with the building's architecture.

Our Electrical Engineering Services

  1. Lighting & Power Layouts
  • ​Technical Detail: Comprehensive design of internal and external lighting systems, including emergency lighting and power distribution networks.
  • ​The Benefit: Optimized illumination levels (Lux calculations) and conveniently placed power outlets tailored to the building’s functional needs.
  1. ​Containment & Cable Management
  • ​Technical Detail: 3D modelling of cable trays, ladders, and conduits within the BIM environment.
  • ​The Benefit: We ensure that electrical pathways do not interfere with HVAC ducts or plumbing lines, reducing “on-site surprises” and installation time.
  1. ​ELV (Extra Low Voltage) Systems
  • ​Technical Detail: Design and integration of data networks, telecommunications, CCTV, Fire Alarm systems, and Access Control.
  • ​The Benefit: A unified digital infrastructure that supports modern smart-building requirements.
  1. ​Panel Schedules & Load Balancing
  • ​Technical Detail: Detailed calculation of electrical loads to ensure balanced distribution and prevent circuit overloads.
  • ​The Benefit: Enhanced system longevity and reduced risk of electrical failures or fire hazards.

Technical Standards & Compliance

We design to meet the most rigorous global standards, ensuring your project is compliant in the world and India:

IEC

International Electro technical Commission standards.

NEC

National Electrical Code.

BS Standards

British Standards for electrical installations.

Local Authority Codes

Adherence to specific utility requirements (e.g., DEWA, SEWA).

The Scanotrek Electrical Advantage

  1. 15+ Years of Mastery: Our deep experience in AutoCAD and Revit allows us to handle complex electrical layouts that many firms find challenging.
  2. ​Precision Coordination: Using Navisworks, we perform "Hard Clash" detection between electrical containment and other building services, ensuring a smooth construction phase.
  3. ​Scan-to-Electrical: For retrofitting projects, we use 3D laser scans to accurately map existing electrical assets, reducing the risk of damaging hidden cables during renovation.

Technical Specs for the Developer

Software Stack

Autodesk Revit (MEP), AutoCAD Electrical, DIALux (for lighting analysis).
Deliverables

3D Coordinated Models, Single Line Diagrams (SLDs), Lighting Calculation Reports, and Detailed Shop Drawings.
LOD Levels

Delivering up to LOD 400 for construction-ready accuracy.

Sustainable & Coordinated Plumbing Engineering Solutions

Advanced 2D/3D plumbing design ensuring efficient water distribution and drainage for complex infrastructure.

The Core Offering

​Plumbing systems are the lifeblood of building hygiene and occupant comfort. At Scanotrek, we design integrated Public Health Engineering (PHE) solutions that prioritize water conservation, pressure optimization, and leak prevention. By leveraging Revit MEP, we model every pipe, slope, and fixture to ensure your plumbing systems work in perfect harmony with the architectural and structural design.

Our Plumbing Engineering Services

  1. Water Supply & Distribution
  • ​Technical Detail: Designing domestic cold and hot water systems, including booster pump sizing, tank calculations, and pipe diameter optimization.
  • ​The Benefit: We ensure consistent water pressure and flow rates across all floors, even in high-rise structures.
  1. ​Drainage & Sanity Systems (Waste & Soil)
  • ​Technical Detail: Precise modelling of gravity-fed drainage systems, including vent stacks and grease traps.
  • ​The Benefit: Using Revit’s slope-modelling capabilities, we ensure that drainage systems are clash-free and functional, preventing costly site modifications to floor slabs.
  1. ​Storm water & Rainwater Harvesting
  • ​Technical Detail: Design of roof drainage, rainwater collection systems, and site-wide storm water management.
  • ​The Benefit: Sustainable solutions that reduce the load on municipal systems and provide eco-friendly water reuse options.
  1. ​Fire Protection (Sprinkler & Hydrant)
  • ​Technical Detail: Strategic placement of fire sprinklers, standpipes, and fire pumps in accordance with safety regulations.
  • ​The Benefit: Fully coordinated life-safety systems that meet the rigorous approval standards of international fire departments.

Technical Standards & Compliance

Our designs adhere to global plumbing codes to ensure your project is compliant in the World:

IPC

International Plumbing Code.

UPC

Uniform Plumbing Code.

NBC

National Building Code (India).

BS EN

British/European Standards for water supply and drainage.

The Scanotrek Plumbing Advantage

  1. Gravity-Flow Precision: Our experts manually model pipe slopes in Revit to ensure "real-world" functionality. We don't just draw lines; we build working systems.
  2. ​Total Coordination: Using Navisworks, we identify "clashes" where plumbing lines might intersect with structural beams or electrical trays, resolving them before the first pipe is laid on-site.
  3. ​Scan-to-Plumbing: For heritage or renovation projects, we use 3D Laser Scans to map existing subterranean or wall-hidden pipes, ensuring new installations integrate perfectly with old infrastructure.

Technical Specs

Software Stack

Autodesk Revit (MEP), AutoCAD, Navisworks Manage.
Deliverables

3D Coordinated Models, Isometric Plumbing Drawings, Pump Room Layouts, and Bill of Quantities (BOQ).
LOD Levels

Capable of delivering up to LOD 400 for construction and fabrication-ready detailing.
